Xinhonghua Concrete-Free Floor Deck Roll Forming Machine, Hot Sale Equipment For Metal Factory In Recent Years

Standard High-End Configuration of Hot-Selling Model

1. Heavy-Duty Hydraulic Uncoiler: 5–10 ton load capacity, hydraulic expansion mandrel for continuous production with large steel coils
2. Feeding & Leveling Unit: Multi-group flattening rollers to eliminate steel bending stress, ensuring wrinkle-free formed panels
3. Main Forming Host: 17–18 sets of precision forming rollers with anti-slip embossing, forming tolerance controlled within ±0.3mm for tight interlocking joints
4. Hydraulic Flying Cut System: On-the-fly cutting without line stop, smooth burr-free cuts without panel deformation
5. Electrical Control Cabinet: Intelligent Siemens PLC touchscreen, storage of 20 sets of profile parameters for one-click size switching
6. Extended Output Support Rack: Heavy-duty tray for neat stacking of finished panels for easy packaging & transportation

Main Downstream Application Scenarios

1. Mezzanine floors of large logistics warehouses & e-commerce storage parks
2. Heavy-duty equipment operation platforms for industrial steel structure factories
3. Multi-story partition floors of prefabricated light steel villas
4. Overhead walkways & temporary load-bearing platforms for overseas prefab construction sites
5. Capacity expansion core equipment for metal profile processing & steel structure supporting factories

Exclusive Xinhonghua After-Sales Support

1. 2-year full machine warranty with discounted supply of wearing parts
2. Lifetime free technical support, 24/7 online remote troubleshooting
3. Direct after-sales service branches nationwide; overseas engineer dispatch for on-site installation & training
4. Over 20 years of cold roll forming technology experience, 48 proprietary patents, customized profile development available
